Aluminum 1 1/2" Female Camlock x 1 1/2" Female NPT 90 Degree Elbow (USA)

Item Number: DA15F15FN90
  • Aluminum 1 1/2" Female Camlock x 1 1/2" Female NPT 90 Degree Elbow (USA)
1 7
$83.05
$0.00 $83.05
Sale Sold out
In Stock (10 or more)
Ships
Estimated transit time: 2 to 5 Business Days Eligible for Express Shipping

Shipping Cost: Free on orders over $100

  • Made In USA
  • Weight: 1.25 lb
  • Body Material: Aluminum
  • Camlock (Cam & Groove) Size: 1 1/2 inch Female
  • Threaded Size: 1 1/2 inch Female NPT
  • Maximum Operating Pressure: 250 PSI
  • Seal: Buna
  • Type: "D" Quick Disconnect

Description

This Aluminum 1 1/2 inch Female Camlock x 1 1/2 inch Female NPT 90 Degree Elbow is a Made in the USA Type "D" quick disconnect coupler. Constructed from aluminum with a Buna seal, it enables efficient and leak-free hose connections. The female camlock side connects to a 1 1/2 inch male camlock, and the female NPT threaded side connects to a 1 1/2 inch male National Pipe Tapered fitting.

Help Me Connect

NPT: National Pipe Tapered is common in plumbing and some industrial uses. Sometimes referred to as pipe thread because PVC pipe and schedule 40 pipe are typically threaded in NPT. As its name implies this is a tapered thread so that the outside diameter of the male (ODM) gets smaller towards the end of the fitting and the inside diameter of the female narrows with depth. As the two fittings are threaded together the opposite tapers force thread friction and makes the seal without the use of a gasket.



Warranty Information

Limited 1-Year Camlock Warranty - We will replace any camlock fitting with manufacturer defects in material and workmanship. All warranty claims must be returned to us for inspection before we determine a solution.

Our warranty does not cover gaskets, multiple use of NPT threads, shipping cost, cosmetic damages, normal wear-and-tear, improper use or chemical damage.

View full details

Additional Details

Type "D" aluminum 1 1/2 inch female camlock (Cam & Groove) coupler to 1 1/2 inch female NPT threads 90° elbow.

Under no circumstances should cam and groove couplings be used for compressed air or steam service!

Connections

  • The female side of this adapter will only connect to a 1 1/2 inch male camlock
  • The female threaded side of this adapter will only connect to a 1 1/2 inch male National Pipe Tapered (NPT), for example, PVC or metal pipe fitting

How it works

  • To make a connection, simply slide the camlock adapter into the camlock coupling and with normal hand pressure, press the cam levers down.
  • Uncoupling is as quick and simple as coupling. Just lift the cam arms and remove the adapter.

Cam and groove couplings, also called camlock fittings or quick connect fittings, are used in most industries as a hose connection to avoid leakage. The cam lock type of coupling is popular because it is considered to be a simple and economical way to reconnect and disconnect.

Cam and Groove Couplings Industries

  • Steel foundries
  • Mines
  • Construction
  • Chemical
  • Petroleum
  • Sanitary
  • Government
  • Nuclear
  • Aviation
  • Marine
  • Rail
  • Storage
  • Dry bulk

Applications

  • Stainless Steel: Use with salt water, waste water, and many chemicals; can also be used with hydraulic oll and coolants
  • Aluminum: Use with water, hydraulic oil, coolants, gasoline, and petroleum products
  • Brass: Use with water, can also be used with hydraulic oil, coolants, gasoline, and petroleum products

Specifications

Female Camlock Dimensions

  • Size: 1 1/2 inches (1.50)
  • Female Inside Diameter: 2 1/8 inches (2.125)

FAQs

What types of connections does this 90 degree elbow offer?

This adapter features a 1 1/2 inch female camlock (Type "D" quick disconnect) on one side and a 1 1/2 inch female NPT thread on the other. It connects to a 1 1/2 inch male camlock and a 1 1/2 inch male National Pipe Tapered fitting, respectively.

What is the maximum operating pressure for this elbow?

The maximum operating pressure for this Aluminum 1 1/2 inch Female Camlock x 1 1/2 inch Female NPT 90 Degree Elbow is 250 PSI.

Can this camlock fitting be used for compressed air or steam service?

No, cam and groove couplings, including this one, must not be used for compressed air or steam service under any circumstances.

How do you connect and disconnect using this camlock adapter?

To connect, slide the camlock adapter into a camlock coupling and press the cam levers down with normal hand pressure. To uncouple, simply lift the cam arms and remove the adapter.

What are the dimensions of the female camlock side?

The female camlock side of this adapter has a size of 1 1/2 inches, with a female inside diameter of 2 1/8 inches.
