Stainless Steel 3/4" Camlock Female Dust Cap

Item Number: GS07DC
  • Stainless Steel 3/4" Camlock Female Dust Cap
1 6
$16.47
$0.00 $16.47
Sale Sold out
In Stock (10 or more)
Ships
Estimated transit time: 2 to 5 Business Days Eligible for Express Shipping

Shipping Cost: Free on orders over $100

  • Weight: 0.41 lb
  • Body Material: 316 Stainless Steel
  • Camlock (Cam & Groove) Size: 3/4 inch Dust Cap
  • Maximum Operating Pressure: NONE
  • Seal: Buna
  • Type: "DC" Quick Disconnect

Description

The Stainless Steel 3/4 inch Camlock Female Dust Cap is a "DC" type quick disconnect fitting designed to seal hose connections and prevent leakage in industrial settings. Constructed from durable 316 Stainless Steel with a Buna seal, it connects securely to 3/4 inch male camlock fittings. This cap provides a simple and economical way to quickly connect and disconnect hoses. It is crucial to note that this dust cap is not rated for pressure applications and must not be used with compressed air or steam for safety and environmental reasons.

Warranty Information

Limited 1-Year Camlock Warranty - We will replace any camlock fitting with manufacturer defects in material and workmanship. All warranty claims must be returned to us for inspection before we determine a solution.

Our warranty does not cover gaskets, multiple use of NPT threads, shipping cost, cosmetic damages, normal wear-and-tear, improper use or chemical damage.

View full details

Additional Details

Global type "DC" stainless steel 3/4 inch female camlock (Cam & Groove) dust cap. Dust caps and dust plugs are not to be used in pressure applications for safety and environmental reasons.

Under no circumstances should cam and groove couplings be used for compressed air or steam service!

Features

  • Finger rings are not supplied on 1/2 inch - 1 inch caps

Connections

  • The female camlock cap will only fit a 3/4 inch male camlock

How it works

  • To make a connection, simply slide the camlock adapter into the camlock coupling and with normal hand pressure, press the cam levers down.
  • Uncoupling is as quick and simple as coupling. Just lift the cam arms and remove the adapter.

Cam and groove couplings, also called camlock fittings or quick connect fittings, are used in most industries as a hose connection to avoid leakage. The cam lock type of coupling is popular because it is considered to be a simple and economical way to reconnect and disconnect.

Cam and Groove Couplings Industries

  • Steel foundries
  • Mines
  • Construction
  • Chemical
  • Petroleum
  • Sanitary
  • Government
  • Nuclear
  • Aviation
  • Marine
  • Rail
  • Storage
  • Dry bulk

Applications

  • Stainless Steel: Use with salt water, waste water, and many chemicals; can also be used with hydraulic oll and coolants
  • Aluminum: Use with water, hydraulic oil, coolants, gasoline, and petroleum products
  • Brass: Use with water, can also be used with hydraulic oil, coolants, gasoline, and petroleum products

Specifications

Female Camlock Dimensions

  • Size: 3/4 inch (0.75)
  • Female Inside Diameter: 1 5/16 inches (1.289)

Download Spec Sheet

FAQs

What is the primary function of this 3/4 inch camlock dust cap?

This 3/4 inch camlock dust cap is designed to seal hose connections and prevent leakage. It offers a simple and economical method for quick connecting and disconnecting in various industrial applications.

What material is the 3/4 inch camlock dust cap made from?

The 3/4 inch camlock dust cap is constructed from 316 Stainless Steel and features a Buna seal.

Can this camlock dust cap be used in pressure applications?

No, this camlock dust cap is not designed for pressure applications and must not be used with compressed air or steam due to safety and environmental reasons. It has no maximum operating pressure rating.

What type of camlock fitting will this cap connect to?

This female camlock dust cap will only connect to a 3/4 inch male camlock fitting.

What are the female inner dimensions of this 3/4 inch camlock dust cap?

The 3/4 inch camlock dust cap has a female inside diameter of 1 5/16 inches.
